| Housing material | Die-cast aluminum |
|---|---|
| Seals material | NBR, HNBR |
| Pneumatic connection 1 | Sub-base, size 3 as per ISO 5599-1 |
| Pneumatic connection 2 | Sub-base, size 3 as per ISO 5599-1 |
| Pneumatic connection 3 | Sub-base, size 3 as per ISO 5599-1 |
| Pneumatic connection 4 | Sub-base, size 3 as per ISO 5599-1 |
| Pneumatic connection 5 | Sub-base, size 3 as per ISO 5599-1 |
| Pneumatic working port | G1/2, Sub-base, size 3 as per ISO 5599-1 |
| Pilot exhaust air port 84 | M5 |
| Degree of protection | IP65 |
| Valve function | 5/2, monostable |
| Lap | Overlap |
| Width | 65 |
| Nominal width | 14.5 |
| Standard nominal flow rate | 4500 |
| Pilot air supply port | Internal |
| Flow direction | Non-reversible |
| Reset method | Mechanical spring |
| Switching time off | 74 |
| Switching time on | 33 |
| Operating voltage | Via solenoid coil, to be ordered separately |
| Min. Operating pressure | 3 |
| Max. Operating pressure | 10 |
| Min. Temperature of medium | -5 |
| Max. Temperature of medium | 50 |
| Min. Ambient temperature | -5 |
| Max. Ambient temperature | 50 |
| Max. positive test pulse with 0 signal | 3700 |
| Max. negative test pulse on 1 signal | 4600 |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Manufacturer part # | 159711 |
| Weight | 1000 |
