| Housing material | Die-cast aluminum |
|---|---|
| Seals material | NBR, HNBR |
| Pneumatic connection 1 | Sub-base, size 1 as per ISO 5599-1 |
| Pneumatic connection 2 | Sub-base, size 1 as per ISO 5599-1 |
| Pneumatic connection 3 | Sub-base, size 1 as per ISO 5599-1 |
| Pneumatic connection 4 | Sub-base, size 1 as per ISO 5599-1 |
| Pneumatic connection 5 | Sub-base, size 1 as per ISO 5599-1 |
| Pneumatic working port | G1/4, Sub-base, size 1 as per ISO 5599-1 |
| Pilot air port 12 | Sub-base, size 1 as per ISO 5599-1 |
| Pilot air port 14 | Sub-base, size 1 as per ISO 5599-1 |
| Degree of protection | IP65 |
| Valve function | 5/2, monostable |
| Lap | Overlap |
| Width | 42 |
| Nominal width | 8 |
| Standard nominal flow rate | 1200 |
| Pilot air supply port | Internal |
| Flow direction | Non-reversible |
| Reset method | Mechanical spring |
| Switching time off | 39 |
| Switching time on | 17 |
| Operating voltage | Via solenoid coil, to be ordered separately |
| Min. Operating pressure | 3 |
| Max. Operating pressure | 10 |
| Min. Temperature of medium | -5 |
| Max. Temperature of medium | 50 |
| Min. Ambient temperature | -5 |
| Max. Ambient temperature | 50 |
| Max. positive test pulse with 0 signal | 3700 |
| Max. negative test pulse on 1 signal | 4600 |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Pilot medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Manufacturer part # | 159687 |
| Weight | 450 |
