| Type | [Laser Sensor] Laser Sensor (Amplifier) |
|---|---|
| Detection Method | [Penetration] Through Beam Type |
| Head shape | [Square] Square shape |
| Case Material | [Resin] Polycarbonate |
| Amplifier accessory type | Amplifier only |
| Operating Environment | Standard |
| Ambient Operating Temperature | −25~40 |
| Ambient Operating Humidity | 35~85 |
| Amplifier function (selectable only when amplified) | Threshold Automatic Correction / External Input / Response time setting / Power Tuning Function |
| Power Supply Voltage | VDC 10–30 |
| Output Format | PNP Output |
| Connection Method | M8 Connector |
| Cord Length | - |
| Timer | User can select from timer function disabled / OFF-delay / ON-delay / one-shot / ON-OFF delay |
| Spot Dia. | - |
| Response time (standard mode) | 10 |
| Accessories (dedicated reflective plate, etc.) | Instruction manual |
| Laser class | - |
| Applicable Sensors | - |
| Input/Output | 1 Output + 1 Input |
