| Type | [Timer] Power Supply Off Delay Timer |
|---|---|
| Display method | [Other] LED lighting on/lighting off |
| Mounting Method | [Other] DIN rail mount |
| Time specifications | 0.1 to 1.2 / 1 to 12 |
| Power Supply Voltage | AC/DC |
| Output Method | Relay |
| Representative Standard | CE / UL / CCC / CSA |
| Dimension vertical | 100 |
| Dimension width | 17.5 |
| Dimension depth | 90 |
| Rated power supply voltage | 24 to 48 V AC/DC |
| Time ranges = N | 2 |
| Contact Configuration | 1c |
| Terminal shape | Push-in Plus terminal |
