| Operating Pressure Range | 0.2～0.8 |
|---|---|
| Seals material | NBR |
| Drive shaft material | Steel, Nickel-plated |
| Size | 16 |
| Adjustment range of swivel angle | 0-180 |
| Swivel angle | 0-180 |
| Cushioning | Elastic cushioning rings/pads at both ends |
| Min. Ambient temperature | -10 |
| Max. Ambient temperature | 60 |
| Max. swivel frequency at 6 bar | 3 |
| Theoretical torque at 6 bar | 2 |
| Pneumatic connection | M5 |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] |
| Manufacturer part # | 11910 |
