| Design | Block design |
|---|---|
| Measuring principle | Magnetic reed |
| Housing material | Epoxy resin, PC, PET, Steel, TPE-O, Die-cast zinc |
| Degree of protection | IP67 |
| DC operating voltage range | 0-200 |
| Operating voltage range AC | 0-250 |
| Max. output current | 1000 |
| Type of mounting | With accessories |
| Cable length | 2.5 |
| Material of cable sheath | PVC |
| Max. switching frequency | 500 |
| Max. switching capacity DC | 40 |
| Tightening torque | 2.9 |
| Switching output | Contact-based, bipolar |
| Min. Ambient temperature | -20 |
| Max. Ambient temperature | 70 |
| Electrical connection | 2-wire, Cable |
| Weight | 100 |
| Manufacturer part # | 30457 |
