| Housing material | Die-cast aluminum |
|---|---|
| Seals material | NBR, TPE-U(PU) |
| Pneumatic connection 1 | G1/4 |
| Pneumatic connection 2 | G1/4 |
| Pneumatic connection 3 | G1/4 |
| Pneumatic connection 4 | G1/4 |
| Pneumatic connection 5 | G1/4 |
| Pneumatic working port | G1/4 |
| Pilot exhaust air port 82 | M5 |
| Pilot exhaust air port 84 | M5 |
| Degree of protection | IP65 |
| Max. switching frequency | 16 |
| Valve function | 5/2, bistable, dominant |
| Lap | Underlap |
| Width | 30.5 |
| Nominal width | 7 |
| Standard nominal flow rate | 1100 |
| Flow direction | Non-reversible |
| Changeover time | 16 |
| Operating voltage | Via solenoid coil, to be ordered separately |
| Min. Operating pressure | 2.5 |
| Max. Operating pressure | 8 |
| Min. Temperature of medium | -5 |
| Max. Temperature of medium | 40 |
| Min. Ambient temperature | -5 |
| Max. Ambient temperature | 40 |
| Min. Storage temperature | -20 |
| Max. Storage temperature | 60 |
| Venting hole connection | M5 |
| Max. positive test pulse with 0 signal | 2200 |
| Max. negative test pulse on 1 signal | 3700 |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class (CRC) | 1 - Low corrosion stress |
| Manufacturer part # | 536194 |
| Weight | 530 |
