| Housing material | Brass |
|---|---|
| Seals material | NBR |
| Valve function | 2/2, closed, monostable |
| Nominal width | 13.5 |
| Standard nominal flow rate | 2400 |
| Max. torque for cover screw | 20 Nm |
| Max. tightening torque for connecting thread | 105 Nm |
| Flow direction | Non-reversible |
| Switching time off | 10 |
| Switching time on | 8 |
| Fitting connection | G1/2 |
| Flow rate Kv | 2.4 |
| b-value | 0.37 |
| C value | 9.8 |
| Min. Temperature of medium | -10 |
| Max. Temperature of medium | 60 |
| Min. Ambient temperature | -10 |
| Max. Ambient temperature | 60 |
| Medium | Compressed air as per ISO 8573-1:2010 [7:4:4], Water, Neutral liquids, Inert gas |
| Corrosion resistance class (CRC) | 1 - Low corrosion stress |
| Manufacturer part # | 546148 |
| Weight | 450 |
