| Seals material | FPM |
|---|---|
| Pneumatic connection 1 | Sub-base |
| Pneumatic connection 2 | Sub-base |
| Pneumatic connection 3 | Not ducted |
| Pneumatic working port | Sub-base, size 30 mm as per ISO 15218 |
| Degree of protection | IP65 |
| Valve function | 3/2, closed, monostable |
| Lap | Underlap |
| Width | 30 |
| Nominal width | 1.3 |
| Standard nominal flow rate | 50 |
| Flow direction | Non-reversible |
| Reset method | Mechanical spring |
| Switching time off | 9 |
| Switching time on | 11 |
| Operating voltage | 24 DC, 42 AC |
| Min. Operating pressure | 1 |
| Max. Operating pressure | 16 |
| Min. Temperature of medium | -15 |
| Max. Temperature of medium | 80 |
| Min. Ambient temperature | -15 |
| Max. Ambient temperature | 50 |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| Manufacturer part # | 119603 |
| Weight | 140 |
