| Housing material | Brass, Steel, Die-cast aluminum, PPS, POM |
|---|---|
| Seals material | NBR, HNBR |
| Pneumatic connection 1 | Common port with pressure separation |
| Pneumatic connection 2 | G1/8 |
| Pneumatic connection 4 | G1/8 |
| Pneumatic connection 11 | Common port with pressure separation |
| Pneumatic working port | G1/8 |
| Pilot air port 12/14 | Common port |
| Degree of protection | IP65 |
| Valve function | 3/2, closed, monostable |
| Lap | Overlap |
| Nominal width | 6 |
| Standard nominal flow rate | 800 |
| Pilot air supply port | Internal<br>External |
| Flow direction | Non-reversible |
| Reset method | Pneumatic spring |
| Switching time off | 30 |
| Switching time on | 24 |
| Valve size | 14 |
| Operating voltage | 24 DC |
| b-value | 0.42 |
| C value | 3.2 |
| Min. Operating pressure | -0.9 |
| Max. Operating pressure | 10 |
| Min. Pilot pressure | 3 |
| Max. Pilot pressure | 8 |
| Min. Temperature of medium | -5 |
| Max. Temperature of medium | 50 |
| Min. Ambient temperature | -5 |
| Max. Ambient temperature | 50 |
| Min. Storage temperature | -20 |
| Max. Storage temperature | 40 |
| Electrical power consumption | 0.65 |
| Max. positive test pulse with 0 signal | 1400 |
| Max. negative test pulse on 1 signal | 400 |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
| Manufacturer part # | 553259 |
| Weight | 120 |
