| Housing material | PBT |
|---|---|
| Pack size | 10 |
| Nominal width | 1.6 |
| Size | Mini |
| Min. Operating pressure | -0.95 |
| Max. Operating pressure | 6 |
| Min. Ambient temperature | -10 |
| Max. Ambient temperature | 80 |
| No. of outlets | 2 |
| Pneumatic connection 1 | External thread M5 |
| Pneumatic connection 2 | for pneumatic tubing outside diameter 3 mm |
| Releasing ring color | Blue |
| Nominal tightening torque | 1.33 |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] |
| Corrosion resistance class (CRC) | 1 - Low corrosion stress |
| Manufacturer part # | 153352 |
| Weight | 3.3 |
