| Housing material | Die-cast aluminum |
|---|---|
| Nominal width | 11.5 |
| Min. Operating pressure | 0 |
| Max. Operating pressure | 16 |
| Min. Ambient temperature | -10 |
| Max. Ambient temperature | 60 |
| No. of outlets | 8 |
| Pneumatic connection 1 | Internal thread G1/2 |
| Pneumatic connection 2 | Internal thread G1/4 |
| Nominal tightening torque | 14 |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] |
| Corrosion resistance class (CRC) | 0 - No corrosion stress |
| Manufacturer part # | 2078 |
| Weight | 230 |
