| Housing material | Die-cast aluminum |
|---|---|
| Seals material | NBR, TPE-U(PU) |
| Valve function | 5/2, monostable |
| Lap | Underlap |
| Standard nominal flow rate | 3700 |
| Pneumatic connection 1 | G1/2 |
| Pneumatic connection 2 | G1/2 |
| Pneumatic connection 3 | G1/2 |
| Pneumatic connection 4 | G1/2 |
| Pneumatic connection 5 | G1/2 |
| Width | 52 |
| Nominal width | 14 |
| Min. Operating pressure | 0 |
| Max. Operating pressure | 10 |
| Min. Pilot pressure | 1.2 |
| Max. Pilot pressure | 10 |
| Min. Temperature of medium | -10 |
| Max. Temperature of medium | 60 |
| Min. Ambient temperature | -10 |
| Max. Ambient temperature | 60 |
| Min. Storage temperature | -20 |
| Max. Storage temperature | 60 |
| Pneumatic working port | G1/2 |
| Switching time off | 27 |
| On switching time | 3 |
| Pilot medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class (CRC) | 1 - Low corrosion stress |
| Manufacturer part # | 9445 |
| Weight | 1070 |
