| Measuring principle | Magnetic reed |
|---|---|
| Housing material | PA, High-alloy stainless steel |
| Degree of protection | IP65, IP68 |
| DC operating voltage range | 5-30 |
| Operating voltage range AC | 5-30 |
| Max. output current | 500 |
| Type of mounting | Screwed tightly, Can be inserted in slot from above |
| Cable length | 5 |
| Material of cable sheath | TPE-U(PUR) |
| Max. switching capacity DC | 10 |
| Switching output | Contact-based, bipolar |
| Min. Ambient temperature | -40 |
| Max. Ambient temperature | 70 |
| Weight | 58.3 |
| Manufacturer part # | 543863 |
